侵彻条件下两类靶体材料静阻力的探讨

程怡豪; 王明洋; 王德荣; 宋春明; 岳松林; 谭仪忠

doi:10.11883/bzycj-2019-0443

侵彻条件下两类靶体材料静阻力的探讨

doi: 10.11883/bzycj-2019-0443

程怡豪^{1, 2,},
王明洋^{1, 3},
王德荣^1, ,,
宋春明¹,
岳松林¹,
谭仪忠¹

1.
陆军工程大学国防工程学院，江苏南京 210007
2.
陆军工程大学野战工程学院，江苏南京 210007
3.
南京理工大学机械工程学院，江苏南京 210094

基金项目: 国家自然科学基金（51409258，11602303，11772355）；江苏省自然科学基金（BK20190570）；中国博士后基金（2018M643853，2018M643854）；江苏省博士后基金（2018K047A）

详细信息

作者简介:
程怡豪（1986－　），男，博士，讲师，05105432@163.com

通讯作者:
王德荣（1968－　），男，博士，副教授，wdrjb@163.com

中图分类号: O347
计量
- 文章访问数: 4459
- HTML全文浏览量: 2123
- PDF下载量: 117
- 被引次数: 0
出版历程
- 收稿日期: 2019-11-19
- 修回日期: 2019-12-27
- 网络出版日期: 2020-04-25
- 刊出日期: 2020-06-01

Discussion on essences of static resistance of two types of material under penetration

1.
National Defense Engineering College, Army Engineering University of PLA, Nanjing 210007, Jiangsu, China
2.
Field Engineering College, Army Engineering University of PLA, Nanjing 210007, Jiangsu, China
3.
School of Mechanical Engineering, Nanjing University of Science and Technology, Nanjing 210094, Jiangsu, China

摘要

摘要: 以空腔膨胀理论为主要理论工具，通过比较侵彻近区塑性材料和脆性材料动力学行为的差异，对两类不同材料静阻力（R_t）的本质进行探讨，并对脆性材料侵彻的若干应用问题提出建议。研究表明：（1）R_t是靶体介质以固体特性抵抗局部扩孔、具有时间平均特性的弹体横截面平均应力，其具体取值随着材料的物理力学特性、侵彻模型、撞击速度等因素而变化，因此不是材料的固有特性。（2）对于塑性靶体的非变形侵彻问题，静态空腔膨胀理论的结果能够对R_t作出比较合理的预测；对于拟流体侵彻问题，一般需要对静态空腔膨胀理论的结果加以修正。（3）脆性材料的R_t主要取决于破碎后介质的力学特性而与完整材料的力学特性关系不大，且与单轴抗压强度之间不满足纯粹的单调关系；当侵彻速度较低时，应考虑侵彻速度对侵彻阻力的强化作用，这种强化作用的本质是内摩擦；当侵彻速度足够高时，脆性材料体现出恒定不变的“动力硬度”，其反映了材料的本征阻力特性。（4）提高脆性材料的侵彻阻力的关键在于减小应力波峰值后环向拉应力的幅值、抑制材料的破碎速度和程度，具体措施包括主动或被动地增加外围压、对基质中添加增韧增强纤维等；为了实现对脆性材料侵彻问题更高精度的数值模拟，建议更加重视对破碎介质动力学特性的研究。
- 侵彻 /
- 塑性材料 /
- 脆性材料 /
- 静阻力 /
- Hugoniot弹性极限 /
- 动力硬度
Abstract: Based on cavity expansion theories, the very essences of static target resistance, i.e. R_t of plastic and brittle materials are discussed by comparing the difference of dynamic behaviors in near region of penetration, and some suggestions about applications of brittle materials for penetration are given. The summary of discussion is shown as follows. Firstly, R_t is the mean and time-averaged stress on the cross section of the projectile, which is the resistance of target materials in solid state against local cavity expanding. The specific value of R_t varies withphysical and mechanical properties of materials, penetration models, impact velocity and other factors, and thus is not an intrinsic property of material. Secondly, for the non-deformable projectile penetrating plastic materials, static cavity expansion theory is proper to predict R_t. For semi-hydrodynamic penetration cases, the results of static cavity expansion theory should be modified. Thirdly, R_t of brittle materials mainly depends on fractured materials, while it is weakly related to intact materials and not completely positively related to uniaxial compressive strength of intact materials. If penetration velocity is relatively low, the strengthening effect of R_t of brittle materials by penetration velocity increasing should be considered in terms of internal-friction. If penetration velocity is high enough, the intrinsic and constant resistance of brittle materials is realized, which is named as dynamic hardness. Fourthly, the key measures to increase R_t of brittle materials are to reduce the amplitude of hoop tensile stress following the peak compressive stress, to lower the crack velocity of materials and to restrain the fragmentation degree of materials. These can be solved by increasing external confining pressure and intensifying the tensile strength and fracture toughness of materials. Furthermore, it is suggested that the dynamic properties of fractured materials should be emphasized to increase the precision of numerical calculations of brittle materials under penetration.
- penetration /
- plastic material /
- brittle material /
- static target resistance /
- Hugoniot elastic limit /
- dynamic hardness

HTML全文

图 1 塑性材料中球形空腔膨胀的响应区域

Figure 1. Response regions of spherical cavity expansion in plastic materials

下载: 全尺寸图片幻灯片

图 2 脆性材料中球形空腔膨胀的响应区域

Figure 2. Response regions of spherical cavity expansion in brittle materials

下载: 全尺寸图片幻灯片

图 3 铝靶侵彻的理论计算与实验结果^[23]对比

Figure 3. Penetration depth intoaluminum targets between results from theoretical calculations and experiments^[23]

下载: 全尺寸图片幻灯片

图 4 不同f_c条件下混凝土R_t的拟合结果

Figure 4. Fitted R_t values of concrete with different f_c values

下载: 全尺寸图片幻灯片

图 5 不同f_c条件下混凝土侵彻深度的实验结果^[28]

Figure 5. Effect of f_c on experimental penetration depth in concrete^[28]

下载: 全尺寸图片幻灯片

图 6 基于球面波的腔壁应力衰减规律^[32]

Figure 6. Decay of spherical wave stresses on cavity ^[32]

下载: 全尺寸图片幻灯片

图 7 完整条件下和损伤条件下脆性材料的强度模型^[34]

Figure 7. Model for strength of intact and damaged brittle materials^[34]

下载: 全尺寸图片幻灯片

图 8 花岗岩和混凝土靶体R_t随撞击速度的变化规律

Figure 8. R_t of granite and concrete varying with impact velocity

下载: 全尺寸图片幻灯片

图 9 花岗岩侵彻深度的实验结果与理论计算结果的预测效果^[21]

Figure 9. Comparison of calculation results with experimental results of penetration depth in granite^[21]

下载: 全尺寸图片幻灯片

表 1 不同学者建议的陶瓷R_t值 (单位：GPa)

Table 1. R_t values of ceramic suggested by different researchers (unit in GPa)

陶瓷种类 Kozhushko等^[37] Sternberg^[36] Rosenberg等^[22]

B₄C 42～49 13.3～14.1 6.4
SiC 25～30 5～11 7.5
Al₂O₃ 20～25 9.2 6.0

下载: 导出CSV
