侵彻爆炸作用下钢纤维混凝土结构的破坏模式

杨石刚; 罗泽; 许继恒; 方秦; 杨亚; 徐国琳; 汤俊杰

doi:10.11883/bzycj-2023-0003

侵彻爆炸作用下钢纤维混凝土结构的破坏模式

doi: 10.11883/bzycj-2023-0003

陆军工程大学国防工程学院，江苏南京 210094

基金项目: 江苏省自然科学基金（BK20180081）；国家重点研发计划（2020TFB20103300）

详细信息

作者简介:
杨石刚（1985－　），男，博士，副教授，youngshg@126.com

通讯作者:
罗　泽（1997－　），男，硕士研究生，luoze0114@126.com

中图分类号: O389
计量
- 文章访问数: 304
- HTML全文浏览量: 78
- PDF下载量: 123
- 被引次数: 0
出版历程
- 收稿日期: 2023-01-03
- 修回日期: 2023-10-24
- 网络出版日期: 2023-12-12
- 刊出日期: 2024-01-11

Failure modes of concrete structure under penetration and explosion

National Defense Engineering College, Army Engineering University of PLA, Nanjing 210094, Jiangsu, China

Funds: LIANG B. Research on projectile penetration into bounded concrete target [D]. Beijing: China Academy of Engineering Physics, 2004: 14-73.

摘要

摘要: 基于大口径发射平台进行了155 mm杀伤爆破榴弹毁伤钢纤维混凝土结构的试验，得到了打击不同位置时结构的破坏情况；结合LS-DYNA数值模拟，分析了不同打击位置和不同命中速度下钢纤维混凝土结构的毁伤效应，讨论了侵彻与爆炸联合作用下钢纤维混凝土结构的损伤过程和破坏模式。结果表明：钢纤维混凝土结构在155 mm榴弹作用下，配置钢筋的顶板和侧墙发生较轻的爆炸成坑破坏，无配筋的前墙发生严重的爆炸震塌破坏。SPG (smooth particle Galerkin method)-结构化ALE (arbitrary Lagrange-Euler)(S-ALE)流固耦合算法能够有效预测钢筋混凝土结构在侵彻和爆炸共同作用下的损伤发展过程和破坏模式。大口径弹体侵彻有限边界靶的加速度时程曲线特征为突增骤减单峰值形式，弹体速度呈现先快速降低后缓慢减小的特征；靶标在基于侵彻损伤的爆炸作用下，主要破坏模式为混凝土块大量崩塌和裂缝的生长，且随着侵彻速度的增加，爆炸造成的毁伤由局部破坏向结构整体破坏发展；混凝土破碎区内，垂直于弹体的钢筋在侵彻作用下达到屈服，板顶和板底的钢筋在爆炸后达到屈服。
