摘要:
电动汽车不可避免的碰撞会导致锂离子电池(LIB)出现缺陷,轻微碰撞后的缺陷电池能否继续使用是未知的。在这项工作中,我们重点研究了缺陷电池的机械性能、电化学性能、安全边界及其衰退机理。首先,使用不同的压头通过准静态加载和落锤冲击制备了三种典型的缺陷电池,即压痕、50%偏置压缩和平板压缩缺陷电池。随后,分别通过准静态平板压缩和充电/放电循环评估其机械和电化学响应。结果发现,缺陷电池的机械性能显著下降,包括内部短路位移、短路载荷和能量吸收能力下降。相较于新电池,缺陷电池还表现出明显的电化学性能退化,包括更严重的容量衰退。此外,通过拆解电池解释了其降解机制,基于隔膜厚度提出电池的机械失效标准。最后,还讨论了加载速度和缺陷类型对缺陷电池性能的影响。加载速度越高,缺陷电池的性能退化越严重,这与惯性效应有关。不同类型的缺陷会导致隔膜厚度和石墨分层的变化,从而造成不同程度的退化。研究结果对缺陷锂离子电池的安全识别和处理研究具有指导意义。
Abstract:
Unavoidable electric vehicle collisions can cause defects in lithium-ion batteries (LIBs), and whether defective batteries after minor collisions can continue to be used is still unknown. In this work, we focus on the mechanical performance and electrochemical performance of defective batteries, safety boundaries, and its failure mechanism. Firstly, three typical defective cells , namely indentation, 50% offset compression and plate compression defect cells, are prepared by quasi-static loading and drop hammer impact with different indenters. These defective batteries did not exhibit voltage drops or temperature increases, indicating that no internal short circuits occurred. Subsequently, their mechanical and electrochemical responses were evaluated through quasi-static plate compression at a loading rate of 1 mm/min and 1C charge/discharge cycling, respectively. It was found that defective batteries exhibited significant deterioration in mechanical performance, including earlier onset of internal short circuit, reduced short circuit force, and decreased energy absorption capacity. Defective batteries also exhibited significant electrochemical performance degradation, with greater capacity loss during cycling compared to new batteries. Further, its degradation mechanism is explained through disassembling the cells. The separator of defective batteries exhibited significant thinning, making it more prone to rupture under secondary loading. Therefore, the mechanical failure criterion of the battery was proposed based on the separator thickness. After 500 cycles, graphite delamination was observed in the defective batteries, whereas the defective batteries without cycling only exhibited cracking. Therefore, the degradation of electrochemical performance in defective batteries is caused by the combined effects of initial defects and cyclic aging stress. The effects of loading speed and defect type on the performance of defective cells are also discussed. Defective batteries subjected to higher loading rates exhibit greater performance degradation, which is related to inertia effects. Different types of defects lead to variations in separator thickness and graphite delamination, resulting in different levels of degradation. Results are instructive for the study of safety identification and treatment of defective lithium-ion batteries.
