Riemann-SPH simulation of hypervelocity impact on basalt material: parameter analysis and validation
-
摘要: 为研究超高速撞击玄武岩材料SPH仿真中的参数影响,基于Riemann-SPH方法对地面超高速撞击玄武岩实验进行了数值仿真分析与验证,发现SPH仿真结果受算法参数与材料模型参数影响较大,同时材料强度模型与损伤模型的影响存在耦合性。具体研究结果表明:超高速撞击SPH仿真中考虑人工应力法可以避免固体冲击数值仿真中出现的拉伸不稳定性;合理的光滑长度内期望粒子数和变分辨率粒子分布方法可以实现计算精度与计算效率的兼顾;地面实验的数值仿真中,不同种材料强度模型和损伤模型在不同内聚力和抗拉强度取值时可以得到相似的撞击响应结果,其中选用准确度较低的模型,可能导致对材料参数与物理规律的误解;材料强度模型和损伤模型的多组参数组合也可能得到相近的仿真结果,说明模型参数的不合理取值也可能得到相近的实验结果,而在保证模型参数合理的情况下,本文数值仿真得到的撞击坑尺寸与动量传递因子与实验误差在10%~20%范围内。相关参数取值方法为开展超高速撞击防御小行星SPH仿真及合理选择参数提供了依据。
-
关键词:
Abstract: To study the influence of parameters in SPH simulations of hypervelocity impacts on basalt material, numerical simulation and validation were performed based on the Riemann-SPH method using experimental data from ground-based hypervelocity impact tests on basalt. It was found that the SPH simulation results are significantly affected by both algorithmic and material model parameters, and there is an interaction between the effects of the material strength model and damage model. Specific findings reveal that applying an artificial stress method in hypervelocity impact SPH simulations helps prevent tensile instability in solid impact simulations; choosing an appropriate expected particle number within the smoothing length and using a variable-resolution particle distribution method can balance computational accuracy and efficiency. In ground-based simulations, different material strength and damage models can produce similar impact responses under varying cohesive and tensile strengths, and selecting a model with lower accuracy may lead to misinterpretation of material parameters and physical laws. Additionally, multiple parameter combinations in the strength and damage models can yield similar simulation outcomes, indicating that incorrect parameter choices may still yield results close to experimental findings. When model parameters are set reasonably, the simulated crater size and momentum transfer factor are within 10-20% error range compared to experimental data. These parameter selection methods provide guidance for conducting SPH simulations of hypervelocity impact for asteroid defense and for making informed parameter choices.-
Key words:
- hypervelocity impact /
- the SPH method /
- planetary defense /
- parameter analysis
-
