摘要:
为预防丙烯在生产使用过程中燃爆危险的发生,利用12L爆炸极限测试仪测定了丙烯在空气中不同初始温度(20~180℃)和不同初始压力(0.1~0.9MPa)条件下的爆炸极限。研究发现:随着初始温度、初始压力的增加丙烯爆炸上限显著升高,爆炸下限略微降低,爆炸极限区域明显变宽。在初始温度为180℃时,随着压力的升高,丙烯爆炸上限增幅明显高于线性增幅,爆炸产物中碳粉含量明显增加,丙烯爆炸下限降幅由线性变为滑梯状曲线。初始温度、初始压力的耦合影响明显高于单因素的影响且对爆炸上限的影响明显高于爆炸下限,在测试温度、压力范围内耦合影响:爆炸上限上升108%,爆炸下限下降18.05%。初始温度单因素影响:爆炸上限上升3.8%,爆炸下限下降3.41%。初始压力单因素影响:爆炸上限上升51.3%,爆炸下限下降2.44%。为此,本文给出了丙烯在不同初始温度、压力下爆炸极限数据的曲线、曲面及其拟合公式。
关键词:
-
丙烯 /
-
爆炸极限 /
-
初始温度 /
-
初始压力
Abstract:
For the purpose of preventing propylene explosion risk in production and use, propylene explosion limit was tested by 12L spherical exlosion device to study the relationship between explosion limits and various initial temperature(20~180℃)or pressure(0.1~0.9MPa)in air. The study found that with the initial temperature and pressure rising,the upper explosion limit obviously elevate,but the low explosion limit decrease slightly,the explosion limit expand. At an initial temperature of 180℃, as the pressure increases the increase of the upper explosion limit of propylene is significantly higher than the linear increase, the content of carbon powder in the explosion products increased significantly, and the lower explosion limit of propylene changed from linear to slide-like curve. The coupling effect of initial temperature and initial pressure is obviously higher than that of single factor, and the influence on the upper explosion limit is obviously higher than that of the lower explosion limit. In the range of test temperature and pressure, the coupling effect is as follows : the upper explosion limit increases by 108 %, and the lower explosion limit decreases by 18.05 %. The single factor effect of initial temperature : the upper explosion limit increased by 3.8 %, and the lower explosion limit decreased by 3.41 %.The single factor effect of initial pressure : the upper explosion limit increased by 51.3 %, and the lower explosion limit decreased by 2.44 %. In this paper, the influence surface and fitting formula of initial temperature and initial pressure on the explosion limits of propylene-air mixtures are provided.
