摘要:
全地形车凭借卓越的环境适应性与非道路通行能力,广泛应用于边防巡逻、救灾运输、森林消防等领域。重大突发事件往往导致区域可达性大幅下降,对全地形车的重复空投作业能力提出了明确要求。然而,空投过程会对车辆产生强烈冲击,重复空投更易引发车辆累积损伤,进而影响其作业可靠性。为此,本文建立了某型全地形车空投系统数值仿真模型,先采用低周疲劳分析方法开展空投寿命评估,再结合J-C损伤模型,系统研究多着陆场景下车辆的空投冲击损伤演化规律及寿命特性。结果表明:全地形车初始最大损伤位置集中于底盘横梁,随着空投次数增加,最大损伤位置会向立柱等结构转移;理想空投条件下,车辆空投寿命为10次,且寿命随着陆速度增大而降低,其中斜向着陆速度的影响最为显著。当纵向、斜向、横向、垂向着陆速度分别达到1m/s、1.5m/s、3m/s、15m/s时,不建议实施空投作业。相关研究成果为保障多着陆场景下全地形车的重复空投作业能力提供了重要技术支撑。
关键词:
-
全地形车 /
-
空投 /
-
累积损伤 /
-
寿命评估
Abstract:
All-terrain vehicles (ATVs) are widely used in border patrol, disaster relief transportation, forest fire protection and other fields due to their excellent environmental adaptability and off-road capabilities. Major emergencies often lead to a significant decline in regional accessibility, putting forward clear requirements for the repeated airdrop operation capability of ATVs. However, the airdrop landing process exerts intense impact on the vehicle, and repeated airdrops are more likely to cause cumulative damage to the vehicle, thereby affecting its operational reliability. To address this issue, this paper establishes a numerical simulation model for the airdrop system of a certain type of ATV. First, the low-cycle fatigue analysis method is adopted to evaluate the airdrop lifespan, and then combined with the J-C damage model, the evolution law of airdrop impact damage and life characteristics of the vehicle under multiple landing scenarios are systematically studied. The results show that the initial maximum damage of the ATV is concentrated on the chassis crossbeams; as the number of airdrops increases, the location of maximum damage shifts to structures such as upright columns. Under ideal airdrop conditions, the airdrop life of the vehicle is 10 times, and the life decreases with the increase of landing speed, among which the impact of oblique landing speed is the most significant. When the longitudinal, oblique, transverse and vertical landing speeds reach 1m/s, 1.5m/s, 3m/s and15 m/s respectively, airdrop operations are not recommended. The relevant research results provide important technical support for ensuring the repeated airdrop operation capability of ATVs under multiple landing scenarios.
