摘要:
聚能射流在水介质中的运动研究较少,导致在水介质中其速度与形态演化规律及影响因素不清晰,且射流水介质中运动学方程缺失。针对上述问题,采用数值模拟与试验相结合的方法,对比研究了铝、钛、锆、铁、铜五种药型罩材料在空气与水介质中的射流演化行为。研究发现,在水介质中,射流速度衰减剧烈,4倍炸高内射流速度下降约80%,且衰减速率与材料密度呈负相关;基于试验及仿真结果,结合流体力学理论,构建了射流在水介质中的速度衰减数学模型,误差为9.8%,影响射流速度衰减过程的主要材料因素权重排序为熔点、强度、密度;药型罩材料密度、强度和塑性是影响水介质中射流演化行为的主要材料因素,其中高密度和高塑性有利于提高射流抗断裂能力,延缓射流离散过程,与空气介质相比,水介质中射流离散程度增加41.4%以上;水介质通过隔绝氧气与冷却效应显著抑制了活性材料的氧化释能,使其射流特征与惰性材料相似。研究结果揭示了水介质中材料属性对射流减速、断裂及离散行为的影响,为水下聚能战斗部的优化设计提供了理论依据。
Abstract:
Research on the underwater motion of shaped charge jets (SCJs) remains limited, leaving the evolution patterns and influencing factors of jet velocity and morphology in this medium insufficiently understood. Furthermore, established kinematic equations describing jet motion in water remain scarce. To address these gaps, a combined numerical and experimental approach was employed to investigate the evolution behavior of jets formed from five distinct metallic liner materials—aluminum, titanium, zirconium, iron, and copper—in both air and water. A three-dimensional Arbitrary Lagrangian-Eulerian (ALE) model of jet flight was established based on ANSYS finite element software to investigate the velocity and stress variations of jets in air and water. Concurrently, an experimental platform for jet flight was constructed, and the dynamic evolution processes in both media were recorded using high-speed imaging. The results demonstrate that jet velocity undergoes significant and rapid attenuation in water, decreasing by approximately 80% within 4 times the standoff distance, and the attenuation rate is negatively correlated with material density. Moreover, based on experimental and simulation results, combined with hydromechanics theory, a mathematical model was developed to predict jet velocity attenuation in water, achieving a Mean Absolute Relative Error (MARE) of 9.8%. Based on this model, the primary material factors influencing the jet velocity attenuation process are identified, with the weighted influence ranked as melting point, strength, and density. Additionally, the density, strength, and plasticity of the liner are the key factors governing jet evolution behavior in water. Specifically, high density and high plasticity effectively enhance the jet's fracture resistance and significantly delay its dispersion process. Notably, the resistance force acting on the jet tip in water can reach up to 2000 MPa, which intensifies jet fracture, leading to an increase of over 41.4% in the degree of jet dispersion compared to that in air. Furthermore, water significantly inhibits the oxidation energy release of the reactive materials via oxygen isolation and cooling effects, rendering their energy release characteristics similar to those of inert materials. These findings elucidate the influence of material properties on jet deceleration, fracture, and dispersion in water, providing a theoretical basis for the optimized design of underwater shaped charge warheads.
